The Diamond Cutting Head Assembly with Filters (P/N 305617-10 / 320303-10) is a compatible nozzle assembly featuring a .010″ (0.25 mm) diamond 20431118-Waterjet-Parts-In-Stock-p.html target='_blank'>20431118-Waterjet-Parts-In-Stock-p.html target='_blank'>Orifice and five internal filter elements to protect against abrasive contamination. It mates to standard cutting heads and is designed for ultra-high-pressure waterjet systems (60 ksi).
Description
The 305617-10 cutting head is built around the platform, using a replaceable diamond orifice to generate the abrasive-laden jet. It includes:
Diamond Orifice: .010″ (0.25 mm) diameter, precision-cut diamond for minimal wear and consistent stream quality.
Filter Pack: Five stainless-steel mesh filter elements (304351) housed in the nozzle body to trap abrasive particles before they reach downstream components, preventing clogging and prolonging mix tube/orifice life.
Body: Stainless-steel nozzle body machined to OEM tolerances, compatible with mounting interfaces.
Specifications
P/N:305617-10
Alternate P/N:320303-10
Orifice Material:Synthetic diamond
Orifice Size:.010″ (0.25 mm)
Filters Included:5 × 304351 stainless-steel mesh filters
Compatibility:2-3 Axis cutting heads
Max Pressure:60,000 psi (4,100 bar)
Operating Media:Water + garnet abrasive
Weight:~0.3 lbs (140 g)
Construction:17-4 PH stainless steel body, ceramic/delivery 1-11024-High-Pressure-Waterjet-Parts-In-Stock-For-Sale-p.html target='_blank'>Seals
