The SP1124 Guide Bush Assembly is a 19 mm precision stainless-steel bushing designed for use in G4 Intensifier Pumps on WaterJet Cutting Machines. It provides accurate piston alignment, minimizes metal-to-metal wear in the cylinder bore, and extends seal life under continuous high-pressure operation.
Specifications
Material: Hardened stainless steel for corrosion resistance and durability
Inner Diameter: 19 mm, matching the piston rod diameter in G4 intensifiers
Function: Centers the piston assembly, reduces side loads, and prevents scoring of the cylinder bore under pressures up to 66 ksi
