Sapphire Long Stem 0.20 mm Orifice Assembly 10002193 Abrasive Water Jet Parts In Stock

Short Description:

Parts:10002193
Sapphire Long Stem,0.20 mm Orifice Assembly

Weight: 0.005 kg
Working pressure: 4137 bar
Material: Diamond, stainless steel, titanium or nickel-based alloy
Where is it located:
Located in the mixing chamber.
What is its function:
Serves to focus the water jet to the required size.
What is it or what does it consist of:
It is a small part in the form of a truncated cone. It consists of a steel body, a retaining ring and a diaphragm made of corundum (sapphire).

INQUIRY

Details

10002193 Abrasive Water Jet Parts In Stock

The 49865850-Waterjet-Parts-p.html target='_blank'>49865850-Waterjet-Parts-p.html target='_blank'>Sapphire Long Stem 0.20 mm Orifice Assembly 10002193 is a high-precision component designed for waterjet cutting systems, particularly compatible with KMT-style cutting heads. This assembly features a synthetic sapphire orifice with a 0.20 mm (0.008 inch) inner diameter, providing exceptional wear resistance and maintaining precise flow characteristics under high-pressure conditions.

Key Specifications:
Orifice Diameter: 0.20 mm (0.008 inch)
Material: Synthetic sapphire
Mounting Type: Long stem, designed for KMT-style cutting heads
Compatibility: Replaces KMT part numbers such as A2260008 and 20459562
Applications: Ideal for cutting applications requiring high precision and durability
