Water Jet Pumps For Sale Marble 1L Accumulator Abrasive Waterjet Cutter

Short Description:

Control: PLC
Reversing: Power-on hydraulic
Cooling control: Cooler/oil, heat exchanger
Water inlet filter accuracy: ≤0.45μm
Oil return filter accuracy: 20μm
Operating temperature: 0-50°c
External: UNF3/8"In/out cooling: NPT1"
Diameter: 0.33mm
Use for Abrasive Waterjet Cutting Machine
Stable pressure
Water Jet Pumps For Sale,Abrasive Waterjet Cutter,Abrasive Waterjet

INQUIRY

Details

Water Jet Pumps For Sale Marble 1L Accumulator Abrasive Waterjet Cutter

Model	KD-38	KD-42	KD-75
Pressure	380Mpa/55,000Psi	420Mpa/60,000Psi	420Mpa/60,000Psi
Flow	3.7L/min	3.7L/min	7.4L/min
Nozzle/sand tube aperture	0.011/0.03	0.011/0.03	0.011/0.03
Power	30KW/40HP	37KW/50HP	75KW/100HP

The Water Jet Pumps For Sale for water jet cutting is the core component of modern high-pressure water jet cutting systems and is widely used for precision cutting in industries such as metal, stone, glass, and composite materials. Its main function is to boost the low-pressure water source to a high pressure of 60,000 to 90,000 psi (about 4,100 to 6,200 bar) through the hydraulic booster principle to drive the Water Jet Cutting Head for efficient cutting.
The Water Jet Pumps For Sale uses the oil pressure in the hydraulic system to push the 1-11508-Abrasive-Waterjet-Parts-With-Good-Quality-Supplier-p.html target='_blank'>Piston, which is connected to the plunger. The low-pressure oil pressure is converted into high-pressure water flow through the ratio of the piston area to the plunger area. This boosting principle is similar to the working mechanism of a hydraulic press, that is, the oil pressure multiplied by the piston area is equal to the water pressure multiplied by the plunger area.
Main components Water Jet Pumps For Sale
Hydraulic system: Provides power to push the booster to perform piston movement.
Booster assembly: The core component, which generates high-pressure water flow by hydraulically driving the plunger.
Accumulator: Stores hydraulic energy to ensure the continuous operation of the booster.
Control system: Regulates and monitors the working status of the pump to ensure stable operation of the system.
