500-15-0070 Focusing Tube 0.040 Abrasive Waterjet Mixing Tube R500

Short Description:

500-15-0070, Focusing Tube 0.040, Mixing Tube R500
Technical Specifications
Part Number:500-15-0070
Inner Diameter (ID):0.76 mm (0.030 in)
Outer Diameter (OD):7.62 mm (0.300 in)
Overall Length (OAL):76.2 mm (3.00 in)
Material:R500 binder-less tungsten carbide
Mass:≈0.1 kg
Operating Pressure:Up to 6 000 bar (87 000 psi)

INQUIRY

Details

500-15-0070 Focusing Tube 0.040 Abrasive Waterjet Mixing Tube R500

The 500-15-0070 is a focusing/mixing tube used in Waterjet and compatible waterjet cutting heads. It is constructed from binder-less tungsten carbide (R500), measures 7.62 mm (0.300 in) OD × 0.76 mm (0.030 in) ID × 76.2 mm (3.00 in) OAL, weighs approximately 0.1 kg, and is rated for operating pressures up to 6 000 bar (≈87 000 psi).

Technical Specifications
Part Number:500-15-0070
Inner Diameter (ID):0.76 mm (0.030 in)
Outer Diameter (OD):7.62 mm (0.300 in)
Overall Length (OAL):76.2 mm (3.00 in)
Material:R500 binder-less tungsten carbide
Mass:≈0.1 kg
Operating Pressure:Up to 6 000 bar (87 000 psi)
