Coned Insert 20454360 Glass Water Jet Cutter Parts

The Coned Insert 20454360 is a high-precision alignment component designed to accurately position and support the orifice and mixing chamber within the Waterjet Cutting Head. This part ensures that the high-pressure water stream is perfectly centered as it passes through the diamond orifice into the mixing tube, creating a consistent, focused jet that delivers clean and accurate cuts on a wide range of materials.

Made from premium stainless steel or tungsten carbide, the 20454360 coned insert offers exceptional wear resistance, dimensional stability, and corrosion protection. Its precisely machined conical geometry provides an exact fit for the orifice assembly, minimizing turbulence and maximizing energy transfer from the pump to the cutting jet.

The Coned Insert 20454360 is compatible with KMT, FLOW, OMAX, BFT, and WSI waterjet systems, and is often used in cutting head rebuilds or preventive maintenance to maintain peak performance and cutting accuracy. When paired with other components like the brass retaining collet, nozzle nut, and diamond orifice, it forms the core of a stable and efficient abrasive cutting system.

Key Features:
OEM-quality Coned Insert for waterjet cutting head assemblies
Provides precise alignment for the orifice and mixing chamber
Ensures stable, focused high-pressure water stream
Made from hardened stainless steel or tungsten carbide for longevity
Compatible with KMT, FLOW, OMAX, BFT, and WSI systems
Resistant to corrosion, erosion, and heat buildup
Essential for maintaining cutting precision and system efficiency

Technical Specifications:
Part Number: 20454360
Material: Stainless Steel / Tungsten Carbide
Function: Orifice Alignment and Sealing
Pressure Rating: Up to 90,000 PSI (6,200 bar)
