Electronic Shift Proximity Sensor B-8345-1 New Waterjet Parts Supplier

Part Number	Replaces Parts	Details
A-10654		1" Diameter U-Cup Seal
A-11367		6 Micron Filter 13" Long
A-12500		Crosshead U-Cup Seal
A-13262		Thermistor Sensor
A-14003-4		Spring .77" ID 1" OD
A-14132-1		Proximity Switch for DWJ Assembly DC Normally Open
A-14345-6		Bit Threading Tool
A-15034-1		70 Durometer O-ring
A-15056-1		Proximity Switch for DWJ Assembly DC Normally Closed
A-18018-8		Sleeve Bearing Split
A-19643-1		87K On/Off Valve Spring Disc
A-19889-30		Linear Rail Block; STD; 30
A-20158-1		Solenoid Valve; 4 Port; 4 Position; 24 VDC
A-20295-1		U-Cup Seal With Wiper; 22 mm ID; 30 mm OD; 5 mm
A-20622-1		Cutting Head Clamp Assembly Nut
A-21703-1		Laser Pointer
A-21775-1		100k, Elbow 1/4 in
A-21842-1		100K 24 Volt Pressure Transducer
A-22161-1		87K 1/4" Coupling
A-22378-1		Single Ended Straight Female 3-Pin Cordset
A-23705-1		10 Micron Breather Vent 3/8" NPT
A-23873-1		Water Separator Filter 29" Long
A-23875-1		Closed Loop 0.35 Micron Filter
A-31184-2		Solenoid Valve; Normally Closed; 2 Port; 2 Position; 24 VDC
B-1163-2		Intensifier Low-pressure Seal Kit (25X)
B-1313-1		70 Micron Inline Nozzle Assembly Filter Screen
B-5077-2		Coning/Threading Kit with Case
B-5491-1		60K Swivel Shaft
B-5703-1		60K Bleed-down Valve High-pressure Seat
B-5724-1		60K Swivel Body; Dual Axis
B-8075-005		Silicone Dipped High Resiliency O-ring
B-8345-1		Electronic Shift Proximity Sensor Assembly

The Electronic Shift Proximity Sensor B-8345-1 is a high-performance inductive sensing device engineered for accurate, non-contact position detection in waterjet intensifiers, hydraulic control units, and industrial automation systems. Designed for reliability under extreme conditions, it provides fast, stable, and precise feedback to control shifting, pressure, and motion sequences.
Constructed with a stainless-steel housing and sealed electronic circuitry, the B-8345-1 proximity sensor offers excellent resistance to oil, coolant, vibration, and temperature variations. It operates on a low-voltage DC supply (typically 10–30 VDC) and delivers a consistent electronic output signal used to monitor or trigger valve shifts, piston positions, and other moving components in high-pressure systems.
The KUNDA B-8345-1 Electronic Shift Proximity Sensor is a critical component for ensuring synchronization and safety in 60K and 87K PSI waterJet Pumps, enabling precise timing and automated control of the shifting process. Built to OEM standards, it guarantees long service life, accurate switching, and stable performance in demanding industrial environments.
