Waterjet Bevel Cutting Head OMAX 5 Axis Waterjet Cutting Head Compatible For Composite Panel

Product Introduction

The Waterjet Bevel Cutting Head is a high-precision 5-axis cutting solution designed for composite panel processing, bevel cutting applications, and advanced CNC waterjet manufacturing.

Compatible with OMAX waterjet systems and various Industrial Waterjet machines, this cutting head provides accurate angle compensation, multi-axis motion control, and superior edge quality for demanding industrial applications.

Designed for ultra-high pressure Abrasive Waterjet Systems, the cutting head efficiently processes composite panels, carbon fiber, fiberglass, aluminum composite panels, honeycomb materials, plastics, metal sheets, and engineered materials.

As a professional waterjet component supplier, KUNDA provides high-quality compatible replacement solutions, OEM services, and complete technical support for global waterjet users.

Technical Specifications

A-axis Rotating Range	±70°
C-axis Rotating Range	Infinite
Positioning Precision	1.5'
Max Rotational Speed	50 RPM
Cutting Precision at Fixed Point	±0.05mm
Rotating Radius	261mm
Automatic Height Measurement	Optional
Max Height	607mm
Max Length	376mm
Max Width	161mm
High Pressure Tube Inlet Thread	1/4 Inch

Advanced 5 Axis Bevel Cutting Technology

This waterjet bevel cutting head utilizes advanced 5-axis motion control technology to perform complex angle cutting, bevel processing, chamfering, and three-dimensional contour machining.

The cutting head automatically adjusts cutting angles throughout the cutting process, allowing manufacturers to create precision beveled edges and complex geometries that are difficult to achieve with standard vertical cutting heads.

This technology significantly improves cutting flexibility and manufacturing capability for advanced industrial applications.

OMAX Compatible Replacement Solution

This OMAX compatible 5 axis waterjet cutting head is designed to provide reliable performance and seamless integration with compatible Waterjet Cutting Systems.

Manufactured to strict quality standards, the cutting head offers stable operation, excellent cutting accuracy, and dependable long-term performance.

It is suitable for replacement projects, machine upgrades, and production line optimization, helping customers improve cutting quality while reducing downtime.

Ideal For Composite Panel Processing

This Waterjet Cutting Head For Composite Panel applications is specifically designed to process advanced composite materials with high precision.

The cutting system can efficiently handle carbon fiber panels, fiberglass sheets, aluminum composite panels (ACP), honeycomb structures, sandwich panels, and engineered composite products without generating heat during cutting.

Since waterjet technology is a cold cutting process, it helps prevent delamination, burning, material distortion, and structural damage while ensuring superior finished product quality.

Superior Edge Quality and Angle Accuracy

The advanced bevel cutting capability allows the cutting head to achieve precise angle compensation and minimize taper during operation.

This results in cleaner edges, more accurate dimensions, and improved finished surface quality.

Manufacturers can reduce secondary machining processes such as grinding, sanding, and polishing, helping improve production efficiency while lowering manufacturing costs.

Ultra High Pressure Abrasive Cutting Performance

Designed for ultra-high pressure abrasive waterjet systems, this bevel cutting head can process:

• Carbon Fiber Panels
• Fiberglass Sheets
• Aluminum Composite Panels
• Honeycomb Panels
• Stainless Steel
• Carbon Steel
• Aluminum
• Titanium
• Engineering Plastics
• Decorative Composite Materials

The optimized internal flow design helps maintain a stable abrasive stream, ensuring consistent cutting quality and reliable production performance.

Applications of Waterjet Bevel Cutting Heads

• Composite Panel Manufacturing
• Carbon Fiber Processing
• Fiberglass Cutting
• Aerospace Components
• Automotive Parts Manufacturing
• Aluminum Composite Panel Fabrication
• Honeycomb Structure Processing
• Architectural Decoration Panels
• Industrial Fabrication
• Custom Engineering Projects

Durable Industrial Construction

Manufactured using high-quality wear-resistant materials and precision-engineered components, this waterjet bevel cutting head is designed for long-term operation under demanding industrial conditions.

The durable construction helps reduce wear, improve reliability, and extend service life while maintaining stable cutting performance.

OEM Customization and Technical Support

KUNDA can provide OEM customization services according to customer requirements, machine specifications, and application needs.

The cutting head can be configured for different waterjet systems, production environments, and material processing requirements.

Our technical team provides installation guidance, maintenance support, and system integration services to ensure optimal cutting performance.

Frequently Asked Questions

What is a waterjet bevel cutting head?

A waterjet bevel cutting head allows automatic angle adjustment during cutting, enabling bevel cutting, chamfering, taper compensation, and complex contour processing.

Is this cutting head compatible with OMAX waterjet systems?

Yes. This cutting head is designed as a compatible replacement solution for OMAX waterjet systems and related industrial applications.

Can this cutting head process composite panels?

Yes. It is specifically designed for composite panel processing, including carbon fiber, fiberglass, aluminum composite panels, honeycomb materials, and sandwich structures.

Why is waterjet cutting suitable for composite materials?

Waterjet cutting is a cold cutting process that prevents delamination, burning, thermal distortion, and structural damage while maintaining high cutting accuracy.

Related Waterjet Products

5 Axis Waterjet Cutting Head | 3D Waterjet Cutting Head | High Pressure Waterjet Pump | Robot Waterjet Cutting Machine | Waterjet Spare Parts

Why Choose KUNDA Waterjet Components

KUNDA specializes in providing professional Waterjet Cutting Solutions and high-quality spare parts for global customers.

We can supply waterjet bevel cutting heads, OMAX compatible cutting heads, 5-axis waterjet systems, dynamic taper compensation heads, high-pressure Intensifier Pumps, CNC Waterjet Machines, Robotic Waterjet systems, accumulators, high-pressure tubing, spare parts, and customized automation solutions.

With professional technical support, OEM customization services, strict quality control, and fast global delivery, KUNDA helps customers improve cutting precision, reduce operating costs, and maximize production efficiency.

Contact Us

If you are looking for reliable waterjet bevel cutting heads, OMAX compatible 5-axis cutting heads, or customized composite panel cutting solutions, please feel free to contact KUNDA for more information and professional support.

Email: info@kundacnc.com
WhatsApp: +86 157 9367 0759
