Water Jet Cutting Pump 4000 Bar Commercial Waterjet Pump System
Water Jet Cutting Pump 4000 Bar Commercial WaterJet Pump System
Product Introduction
The 4000 Bar Water Jet Cutting Pump is a commercial continuous duty waterjet pump system designed for high-pressure industrial cutting applications. Built for stable long-term operation, this Waterjet Cutting Pump provides continuous ultra-high pressure water flow for processing metal, stone, glass, ceramics, composites, rubber, foam, and other industrial materials. The advanced intensifier system and high-quality hydraulic components help ensure stable pressure output, smooth cutting performance, and high production efficiency during continuous industrial operation.
Technical Specifications
| Rated Power | 37KW / 40HP |
| Max. Operating Pressure | 480MPa / 69000psi |
| Continuous Working Pressure | 380MPa - 420MPa |
| Max. Discharging Rate | 4.2L/min |
| Orifice Diameter | 0.33mm or others |
| Nozzle Diameter | 1.02mm or others |
| Tank Volume | 150L |
| Machine Size | 1800mm × 1100mm × 1300mm |
| Weight | 900KG |
| Ambient Operating Temperature | Min. 40°F / 5°C, Max. 104°F / 40°C |
| Max. Noise Level | 75 dB(A) |
| Attenuator Volume | 1L / 2L |
Stable 4000 Bar High Pressure Output
The waterjet pump system is capable of generating stable 4000 bar ultra-high pressure water flow for efficient and accurate cutting performance. Stable pressure output helps maintain smooth cutting edges, reduce material waste, and improve cutting precision. The optimized hydraulic intensifier structure minimizes pressure fluctuations during long continuous operation.
Commercial Continuous Duty Design
This commercial waterjet cutting pump is designed for continuous industrial production environments where stability and durability are essential. The heavy-duty structure, high-quality components, and professional cooling system support long-term operation while reducing downtime and maintenance frequency.
Efficient and Energy Saving Performance
The 4000 Bar Waterjet Pump system combines strong cutting power with optimized energy efficiency. The hydraulic transmission system improves pressure conversion efficiency while reducing unnecessary energy consumption during operation. Stable system control and optimized component design help lower operating costs and improve production efficiency.
Wide Material Cutting Applications
This high-pressure water jet cutting pump can be used for cutting stainless steel, carbon steel, aluminum, copper, titanium, marble, granite, ceramic tiles, glass, plastics, rubber, foam, and composite materials. Waterjet cutting technology does not generate heat during processing, helping avoid thermal deformation, cracking, burning, or material damage.
Reliable Industrial Waterjet Solution
The commercial Water Pressure Pump system is manufactured with durable hydraulic technology and high-quality components to ensure long service life under demanding industrial environments. High-quality seals, cylinders, and intensifier components help improve operational stability and reduce maintenance costs.
Why Choose KUNDA Waterjet Pump Systems
KUNDA provides professional Waterjet Cutting Solutions for global customers. We can supply waterjet cutting pumps, CNC Waterjet Machines, Intensifier Pump systems, cutting heads, accumulators, high-pressure tubing, on/off valves, nozzles, orifices, and compatible spare parts for major waterjet brands.
Contact Us
If you are looking for reliable high-pressure Waterjet Pumps, waterjet spare parts, or customized waterjet cutting solutions, please feel free to contact KUNDA for more information and professional support.
